    Sany SCC1000A Used Crawler Crane 100 Ton with 13m 64m Boom length

    Used Sany 100 Tons Crawler Crane-Model 2016


    Product Discription
    Sany SCC1000AUnitParameter

    Configuration

    Max. rated lifting capacityt100
    Boom lengthm13~64
    Boom luffing angle°30~80

    FJ

    Max. rated lifting capacityt11
    Jib lengthm9~18
    Longest boom + longest jibm52+18
    Jib angle°15,30

    Speed

    Rope speed of main/aux. winch (1st layer)m/min121
    Rope speed of boom hoist winch (3rd layer)m/min59
    Swing speedrpm2.7
    Travel speedkm/h21

    Wire rope

    Main hoist wire rope: diameter × lengthφmm×m26×240
    Aux. hoist wire rope: diameter × lengthφmm×m26×180
    Single line pull of main/aux. hoist wire ropet12

    Engine

    Model/Displacement6HK1/7.79L
    Rated power/Revolution speedkW/ rpm212/2000

    Transport

    Weight of machine with basic boomt91t
    Rear counterweightt31.2
    Carbody counterweightt5.5×2
    Transport weight of basic machine (with crawler frames and boom base)t46.5t
    Transport weight of basic machine (without crawler frame)28.5 t
    Machine transport dimension (with crawlers and boom base) L×W×Hmm13300×3490×3450mm
    Machine transport dimension (without crawlers and boom base) L×W×Hmm8450×3000×3050mm
    Other specificationsAverage ground pressure (basic boom)MPa0.091
    Gradeability%30
